Planet Ruler Documentation

Measure planets with nothing but a camera.

Overview

Planet Ruler is an open-source Python library for measuring planetary radii from photographs using computer vision and geometric optimization. The project serves an educational mission, making planetary science accessible to educators, students, researchers, and hobbyists using consumer cameras and smartphones.

The method works by analyzing the curved shape of the visible horizon in photographs taken from altitude. Earth’s curvature becomes geometrically detectable from as little as 1-34 meters above the surface with modern cameras, though the “sweet spot” for clear measurements is high-altitude photography (balloon flights, aircraft, satellites) where curvature is obvious and easily measured.

Core Principles

Transparency over automation: Users are involved in assumptions and trade-off decisions rather than relying on black-box algorithms
Method-agnostic design: No favoratisim; broad toolbox fosters comparative learning
Scientifically rigorous: Real measurements, honest uncertainty
Educational accessibility: Complete documentation from geometric foundations to implementation details

Key Features

Three Computer Vision Approaches

Manual annotation: Interactive GUI for precise limb point selection and user engagement
Gradient-field optimization: Novel detection-free method using image gradients and multi-resolution processing
ML segmentation: Fully automated (or user-assisted) scene segmentation

Comprehensive Toolset

Automatic configuration: EXIF metadata extraction for camera parameters across multiple manufacturers
Image preprocessing: Cropping, orientation correction, gradient enhancement
Robust optimization: Global optimizers (differential evolution, basin-hopping, dual annealing)
Uncertainty quantification: Bootstrap resampling and covariance estimation
Benchmarking framework: Systematic performance testing with YAML configuration and SQLite storage
Professional CI/CD: 700+ tests, comprehensive coverage analysis, automated deployment

Multi-Platform Support

Command-line interface for batch processing
Python API for programmatic access
Interactive Jupyter notebooks for education
Cross-platform (Linux, macOS, Windows)

How It Works

When photographed from altitude, Earth’s horizon appears as a curved arc rather than a straight line. The arc’s curvature encodes the relationship between planetary radius \(R\), observation altitude \(h\), and camera orientation. By measuring this curvature with known camera parameters, we can infer \(R\) (if \(h\) is known) or \(h\) (if \(R\) is known).

The mathematical foundation relates horizon distance \(d_h\) to planetary geometry:

\[d_h = \sqrt{2Rh + h^2} \approx \sqrt{2Rh}\]

For typical aircraft altitudes (10-20 km), the horizon is approximately 357-505 km away, creating measurable curvature in camera images with 4000+ pixel resolution.

Key Insight: The sagitta (vertical extent of the curved horizon) scales as \(s \propto \sqrt{h}\), meaning higher altitude provides gradually improving signal rather than dramatic threshold effects. This enables measurements across a wide altitude range.

Quick Start

Determine Earth’s radius from a horizon photograph:

from planet_ruler.observation import LimbObservation

# Load image with camera configuration
obs = LimbObservation(
    image_filepath="horizon_image.jpg",
    fit_config="config/earth_balloon.yaml"
)

# Manual annotation (most accurate, educational)
obs.detect_limb(detection_method="manual")
obs.fit_limb()

# Display results with uncertainty
print(f"Radius: {obs.radius_km:.1f} ± {obs.radius_uncertainty:.1f} km")
print(f"Altitude: {obs.altitude_km:.1f} km")

# Visualize fit
obs.plot()

Alternative detection methods:

# Detect horizon using gradient-field method (automatic, lightweight)
obs.fit_limb(
    loss_function="gradient_field",
    resolution_stages="auto",  # Multi-resolution optimization
    max_iter=1000
)

# Segmentation (robust to scene complexity)
obs.detect_limb(detection_method="segmentation")
obs.smooth_limb(method="rolling-median", window_length=15)
obs.fit_limb()

For Earth from commercial flight altitude (~10 km), expect radius measurements of 6371 ± 50 km. Higher precision requires careful calibration and multiple images.

Image preprocessing:

# Crop to region of interest for faster processing
obs.crop_image()

# Automatic EXIF-based configuration
from planet_ruler.camera import create_config_from_image
auto_config = create_config_from_image("IMG_1234.jpg", altitude_m=10_000)
obs = LimbObservation(
    image_filepath="horizon_image.jpg",
    fit_config=auto_config
)

Scientific Background

The Scientific Background documentation covers:

Historical methods: Eratosthenes (240 BCE) to modern satellite geodesy
Geometric foundations: Limb arc concept and horizon distance formulas
Minimum detectable altitude: Earth’s curvature visible from 1-34m with modern cameras
Camera specifications: How sensor resolution and focal length determine measurement capability
Mathematical methodology: Coordinate transforms, projection, and optimization
Detection approaches: Manual, gradient-field, and segmentation methods
Gradient-field theory: Flux-based cost functions and multi-resolution strategy

The key scientific contribution is demonstrating that Earth’s curvature is geometrically detectable from ground level with consumer equipment — the “sweet spot” exists because curvature becomes obvious and easily measured at aircraft altitudes, not because it’s invisible below them.
